Turn your ground ore into doré. Complete carbon-in-pulp / carbon-in-leach production lines — engineered, supplied and commissioned at every tonnage from 100 to 1,000 t/d.
After crushing and grinding, cyanide dissolves gold from the slurry while activated carbon recovers it continuously — CIL (carbon-in-leach) adds carbon into the same tanks where leaching happens; CIP (carbon-in-pulp) moves slurry through dedicated adsorption tanks. Both routes recover gold from even fine and preg-robbing ores, replace mercury, and suit oxides, transition ores and concentrate regrind. We deliver the complete line — tanks, screens, desorption & electrowinning, carbon regeneration and smelting — plus the stainless piping and fittings the circuit runs on.
Leach, adsorb, strip, regenerate and smelt — no missing links, no third-party interface problems between stages.
SS304/316 piping, launder pipes, inter-stage screens and tank internals built for cyanide service.
Retention time, carbon loading and tank sizing based on your tonnage, grade and pulp density — with on-site commissioning support.
| Line Item | 100 t/dSmall Mine / Pilot | 300 t/dMid-Scale Plant | 500 t/dIndustrial Plant | 1,000 t/dLarge Operation |
|---|---|---|---|---|
| Crushing & Grinding | ||||
| Jaw Crusher | PE-400×600 | PE-500×750 | PE-600×900 | PE-750×1060 |
| Ball Mill | MQ-1200×2400 | MQ-1500×3000 | MQ-1830×4500 | MQ-1830×6400 ×2 |
| Mill Power (kW) | 37 | 90 | 132 | 2×210 |
| Leaching & Adsorption | ||||
| CIL / CIP Tanks | 5 × CJ-50 (250 m³) | 6 × CJ-100 (600 m³) | 6 × CJ-200 (1,200 m³) | 6 × CJ-400 (2,400 m³) |
| Retention Time (h) | 24 | 24 | 24 | 24 |
| Inter-stage Screens | 5 sets | 6 sets | 6 sets | 6 sets |
| Carbon & Gold Recovery | ||||
| Desorption & Electrowinning | DE-300 | DE-300 | DE-600 | DE-1200 |
| Carbon Regeneration | RK-1500 (1–3 t/d) | RK-1500 ×2 | RK-1500 ×3 | RK-1500 ×4 |
| Acid Washing | AW-300 | AW-300 | AW-600 | AW-600 ×2 |
| Melting Furnace | MF-50 | MF-50 | MF-100 | MF-100 ×2 |
| Plant Support | ||||
| Installed Power (approx.) | ~250 kW | ~500 kW | ~850 kW | ~1,500 kW |
| Plant Area (approx.) | ~700 m² | ~1,400 m² | ~2,200 m² | ~3,800 m² |
Reference configurations for typical oxide ore — final equipment selection is engineered to your ore hardness, head grade, pulp density and recovery target. Piping, valves, pumps, electrical panels and instrumentation quoted with each package. Retrofits and CIL/CIP upgrades of existing plants also available.
Tell us your daily tonnage, ore type and site power. Get a complete CIL / CIP plant quotation with factory-direct pricing.
Request a Plant Quotation
